Handset Remotes

HHC HSW306 Remote Controller 6 Button

$149.00

In stock

Replacement HHC electric recliner HSW306, is a 6 button power recliner remote control wand with USB charge port used to operate electric recliner chairs, sofas and lift recliner chairs with triple actuators. The cable is part straight & part coiled & has a straight 7 pin din plug. HHC Electric Recliner Chair Controller 2 Button Remote for recliner chair or lift chair controller replacement with 6 large illuminated and easy to press buttons and a handy USB charge port. 'You Can Do It' Yourself and Save $$$. Easy fitting in under 5 minutes. No handyman skills required and no tools or experience required. read more

SKU:
E-HAND155
Brand:
HHC
Weight
0.21 kg
Dimensions
18 × 12 × 4 cm
view all details

Description

HHC Electric Recliner Remote Controllers

A replacement HSW306, 6 button 7 pin electric lift chair and standard electric recliner remote, with 6 easy to use illuminated buttons. This electric recliner chair replacement remote controller comes ready to install and is designed to control the footrest/backrest, headrest and lumber mechanisms.

Features Include USB port, part straight and part coiled cable 1000mm (approximately) total length and straight 7 pin din plug.

Fits comfortably in your palm, clear and easy to push buttons and responsive smooth operation are just some of the benefits of installing a quality part from Sofa Rehab.



Australia's Leading Supplier of Recliner Chair Spare Parts

We’re Australia’s Leading Supplier for Repair Kits and Spare Parts. Get the lowest prices on DIY repairs and if your a trades person who needs to buy in bulk, we also offer bulk buy discounts

Save Time & Money and Do It Yourself

With our wide range of repair products, our easy step-by-step instructions and video tutorials, you’ve got everything you need to repair it yourself.  Feel great about having done the repair yourself and saved $$$ on the repair.

Technical Specifications

Technical Specifications

Make – HHC
Model – HSW306
Cable Length – 1000 mm (approximately) straight cable.(Extension cable not supplied)
Handset size – 150 x 42 x 27mm. (Sizes taken end to end and centre)
Plug Type – Straight 7 pin din.
USB Rating – 5v 2A.

How To

How To

Unplug all power to the recliner and remove the mains plug from the wall socket. Lay down a drop sheet on the floor in front of the recliner chair.
Carefully turn the recliner over on its front side to gain access to the recliner wiring underneath.
Locate where the original cabling currently fits and make notes of how it’s routed (recommended to take a photo).
Cut and remove any cable ties holding the cable in place then unplug it from the actuator motor.
You should be able to remove fully the broken controller from the recliner.
Feed the replacement controller through the outside arm.
Secure any free cabling into the same position as the original using cable ties, be sure to check the cable is not caught up and not too tight or at risk of being trapped during motion.
Carefully turn the recliner back over to the standing position.
Test the replacement controller by operating the recliner to its maximum opening and closed position. When fully open, look inside to see that the cabling is safely out of harms way and is not stretched or pinched. Test USB port.

Reviews (0)

Thank you for making an effort to leave a reivew but to protect against spam we only accept reviews from verified owners. Please proceed to login using the same email address you used when ordering the product.
Customer Login

  • There are no reviews yet.

FAQs

FAQs

Will this fit my Lift chair?

Yes, If the model number is HSW306 and the furniture has 3 x actuator/motor and the same plug type it will fit. This is not a universal remote.

How long can this handset reach?

The overall length of the cable is approximately 1000mm long.

My remote has different name/numbers will it still work?

No.

Does this have a USB Charger?

Yes it has a USB port located on the end of the remote.

I have a normal electric recliner chair will this fit?

No.

Do I need an extension lead as well?

Depends on the furniture set up. We sell the remote that links into an extension lead but we do not stock of sell the extension lead.

My handset has less than 6 buttons, will this remote work?

No, this remote is for 6 button remote versions only.
