Cup Holders

6 Button Power Recliner Cup Holder MLZB020-D1

$80.00

In stock

Power recliner cup holder control replacement with 6 back-lit touch buttons and a 7x changeable colour base ring to complement any mood is suitable for electric recliner chairs, sofas and theatre lounges. Mulin Electric model number MLZB020-D1 couch armrest cup holder has 6 buttons to control feet up/down, headrest up/down and lights on/off and a home button feature. Great for electric theatre lounges. Electric Recliner Armrest Cup Holder Replacement. Commonly found in brands like Amart, Harvey Norman, Synargy Smart Comfort and many more. Mulin Electric produced replacement electric recliner cup holders. 'You Can Do It' Yourself and $$$ Easy fitting in under 10 minutes with no experience required. Fit with the 4x screws located in the base of the cup holder. read more

SKU:
E-CUP20
Brand:
Mulin Electric
Weight
0.37 kg
Dimensions
11.5 × 11 × 11.5 cm
Cup Holder Types

Integrated Controls

Description

MLZB020-D1 Power Recliner Cup Holder Control Replacement

This replacement electric recliner couch cup holder is fitted into the armrest of the power recliner chair, couch or theatre lounge and has the 6 x illuminated touch control buttons to operate the footrest, headrest and lights with a Home button feature. Fitted into the armrest of the electric power recliner for a quality appearance. Includes a 5 pin plug to connect to actuator (motor) and a system plug. Mulin Electric model number MLZB020-D1.

Note this is not compatible with MLZB020 (click here) or MLB020-B1 (click here) we sell these also.

* This cup holder is not suitable for use in the USA and Canada.

Save Time & Money and Do It Yourself

The replacement is easy to fit with no experience required. Use the 4x screws located on the base of the cup holder to fit. The size of the unit is 110mm span across the illuminated buttons and will fit a hole diameter of 87mm. We sell the clear acrylic insert separately if required.

Australia's leading supplier of recliner chair spare parts

We’re Australia’s Leading Supplier for Repair Kits and Spare Parts. Get the lowest prices on DIY repairs and if your a trades person who needs to buy in bulk, we also offer bulk buy discounts.

Technical Specifications

Technical Specifications

Model number – MLZB020-D1.
Size – 110mm span across the illuminated buttons
Frame hole – Will fit a hole diameter of 87mm
Rating – Input DC29V Output 12V 1A
For all dimensions watch the short product information video found in the main product photo gallery.

How To

How To

Disconnect power to the item
Press touch buttons to confirm no power to the cup holder or item
Remove clear plastic inner cup and foam pad
Tip over lounge/chair and unplug the 5 pin plug from the actuator and system plug and tip lounge/chair back over
Remove the 4 screws at the bottom of the cup holder and remove cup holder
Insert replacement cup holder leads and plastic housing into position
Screw the 4 screws back into place
Tip over lounge/chair again and locate leads and plug in
Tip back over insert foam pad and clear plastic inner cup
Reinstate the power.

Reviews (2)

Thank you for making an effort to leave a reivew but to protect against spam we only accept reviews from verified owners. Please proceed to login using the same email address you used when ordering the product.
Customer Login

  • Ruth

    Product was exactly what we needed & quick postage

  • Tony Hord

    (verified owner)

    What a fabulous company to deal with 🙂

    Not only did they have the right product, but they also provided some technical support through the “Ask Us” feature on the page.
    I will certainly save their contact information for the future.
    Tony

FAQs

FAQs

Where do I find the model number?

Remove the cup holder from the arm of the recliner and the model label is found on the bottom of the cup holder housing.

Will this fit my recliner?

To be sure of the correct dimensions watch our short product video found in the main product pictures.

Do you sell the clear acrylic inserts?

Yes, we sell the clear acrylic inserts (click here).

Can I change the LED colour?

Yes, there are popular 7 colour options, simple press and hold the 'Light' button to scroll through and then release the button on the preferred colour. The cup holder retains the colour selection for the next time you use it.

Does the LED lights stay on permanently?

No, the manufacturers have built in a pre-set timer, after a period of time the lights will automatically turn off and then require a button to be pressed to turn back on.

Will this link to my other cup holders and light bars?

Yes, you need to select the same frequency setting on all cup holders switch boxes to ensure the lights all match.

Is it easy to fit this cup holder?

Yes, very simple to do, follow our step by step installation guide found in the 'How to' tab.
